Panasonic 315L GL 6kW Compressor

Panasonic 315L GL 6kW Compressor

Supply Only $6,160.00

Supply & Install $6,340.00 Supply & Installation Orders
To order supply and installation, call:
(02) 9627 5447
Additional $185 if a tempering valve is required.


Category Brand:

Description

Commercial-Grade Performance for Large Families

The 6kW CO2 compressor combined with 315L capacity delivers exceptional performance. With a COP of 6.11, this system generates more than six units of heat for every unit of electricity consumed. Penrith Hot Water customers with larger households experience dramatically lower energy bills compared to traditional gas or electric systems.

Abundant Hot Water with Fast Recovery

315L capacity suits families of five or more. The commercial-grade 6kW compressor ensures rapid tank recovery, even with high demand. Top-down stratified heating means usable hot water is available almost instantly. Multiple simultaneous uses—showers, baths, and appliances—run without compromise across Penrith, Emu Plains, and Kingswood.

Industry-Leading Efficiency

The COP of 6.11 is exceptional in residential heating. This means superior energy savings month after month. Larger households in the Greater Nepean see significant reductions in energy costs while enjoying consistent comfort and reliability.

Japanese Engineering for Australian Climate

This system operates flawlessly from -10°C to +43°C without backup heating elements. The 6kW Japan-made compressor handles every Australian season with precision engineering. Greater Nepean households benefit from dependable hot water year-round.

Durable Vitreous Enamel Protection

The glass-lined steel cylinder resists corrosion in Australian water conditions. Magnesium anode protection extends tank life significantly. Your investment is backed by a comprehensive 10-year parts and labour warranty.

Natural CO2 Refrigerant Technology

R744 CO2 refrigerant is natural, non-flammable, and exceptionally efficient—particularly in cold conditions. This eco-friendly technology performs where older systems struggle, making it ideal for Australian climates and reducing environmental impact.

Smart Control Anywhere, Anytime

The external Wi-Fi controller and mobile app put hot water management in your hands. Monitor consumption patterns, adjust schedules remotely, and optimise efficiency from anywhere. Modern convenience meets energy responsibility.

Nearly Silent Operation

At just 37 dB(A), this system runs quieter than normal conversation. Your home remains peaceful while delivering commercial-grade heating performance.

Government Rebates Reduce Investment

The Panasonic 315L 6kW CO2 heat pump qualifies for multiple rebate schemes: STCs (Small-scale Technology Certificates), ESS, and VEEC. Supply and installation packages include instant discounts at checkout. Penrith Hot Water manages all paperwork—you benefit from immediate savings.

WaterMark Certified Quality

This system meets all Australian WaterMark standards, confirming safety and reliability for household use.

Premium Solution for Demanding Homes

If your larger household needs fast recovery and consistent hot water supply, the 315L 6kW combination delivers. Penrith families with multiple bathrooms, high usage patterns, or commercial-adjacent demand appreciate this premium performance.


Why Choose This Product?

  • Panasonic Reputation: Trusted brand with proven heating expertise
  • Industry-Leading COP 6.11: Outstanding energy efficiency reduces bills significantly
  • Larger Capacity: 315L suits families of five or more
  • Commercial-Grade Compressor: 6kW capacity for rapid recovery and high demand
  • Ultra-Fast Recovery: Perfect for large households with simultaneous usage
  • Durable Cylinder: Vitreous enamel glass-lined steel with magnesium anode
  • Extended Warranty: 10 years parts and labour—comprehensive protection
  • Rapid Heat Delivery: Top-down stratified design for immediate comfort
  • Natural Refrigerant: CO2 is safe, efficient, and environmentally responsible
  • Smart Wi-Fi Control: Monitor and manage from your smartphone anytime
  • Ultra-Quiet: 37 dB(A) barely noticeable operation
  • No Backup Elements: Reliable heating across all Australian temperatures
  • Government Rebates: Multiple schemes reduce upfront investment
  • WaterMark Certified: Meets all Australian safety and quality standards
  • High-Demand Ready: Commercial-grade performance for busy households
  • Local Support: Penrith Hot Water provides expert installation and maintenance across Penrith, Emu Plains, Kingswood, and Greater Nepean

Product Details

Brand: Panasonic

Model: HE-UM60CR-PHE-315AGR

Type: CO2 Split System Heat Pump

Capacity: 315L

Cylinder Material: Vitreous Enamel Glass-Lined Steel

Cylinder Protection: Magnesium anode

Compressor: 6.0kW (Model HE-UM60CR, Japan-made, commercial-grade)

Refrigerant: R744 (CO2 – 900g, natural and non-flammable)

Control: External Wi-Fi controller with mobile app

Insulation: Premium high-density polyurethane

Connections: Dual handed for flexible installation


Technical Specifications

Specification Details
Model HE-UM60CR-PHE-315AGR
Capacity 315L
Cylinder Material Vitreous Enamel Glass-Lined Steel
Compressor Capacity 6.0kW
COP (AS 5125) 6.11
Heating Element 5.00
Insulation 50mm high-density polyurethane
Annual Power Input / Output 0.83kW / 5.06kW
Refrigerant R744 (CO2 – 900g)
Noise Level 37 dB(A)
Tank Weight (Empty) 92 kg
Heat Pump Weight (Empty) 46 kg
Maximum Water Pressure (PTR) 850 kPa
Maximum Water Pressure (Mains) 500 kPa
Tank Water Connections 3/4″ Female BSP
Heat Pump Water Connections G1/2 B
WaterMark Certification Yes

Dimensions

Cylinder (Tank)

  • Height: 1764 mm
  • Diameter: 623 mm

Tank Connection Heights

  • Hot Out / HP Return / PTR: 1537 mm
  • Cold In / HP Flow: 201 mm
  • Sensor Port: 551 mm

Heat Pump Unit

  • Height: 672 mm
  • Width: 821 mm
  • Depth: 299 mm

Warranty Information

Parts and Labour Warranty: 10 years

Warranty conditions apply. Penrith Hot Water provides comprehensive warranty support and dedicated maintenance for every Panasonic 315L 6kW installation across Penrith, Emu Plains, Kingswood, and the Greater Nepean.


Delivery Information

We offer free delivery to the following regions:

  • Penrith
  • Emu Plains
  • Kingswood
  • Glenmore Park
  • Cranebrook
  • Surrounding suburbs in the Greater Nepean

Important: All deliveries must be within 50 km of a town with a population over 30,000.

If you’re located outside these areas, please phone us to check availability and discuss delivery options. Note that purchases outside our standard delivery zones will be refunded if free delivery cannot be provided.


STC Information

All supply and installation prices include STCs assigned to us as a point-of-sale discount.

All supply only prices require the customer to claim the STCs themselves.

What Are STCs?

Small-scale Technology Certificates (STCs) are Australian government rebates on eligible hot water systems. The Panasonic 315L 6kW CO2 heat pump qualifies, reducing your overall cost.

Your Options

Supply and Installation: STCs are applied at checkout—no paperwork needed. Immediate savings on your investment.

Supply Only: You’ll claim the STCs yourself. We’ll provide the documentation to streamline the process.

For current rebate amounts on the Panasonic 315L 6kW CO2 heat pump, contact Penrith Hot Water for a free quote.


Downloads

Panasonic Heat Pump Range Brochure

Panasonic C02 Spec Sheet


Ready to Upgrade?

Experience industry-leading efficiency with COP 6.11 and rapid recovery for larger households. The Panasonic 315L 6kW CO2 heat pump combines commercial-grade performance with 10-year warranty protection for families across Penrith, Emu Plains, Kingswood, and the Greater Nepean.

Get your free quote today. Contact Penrith Hot Water to arrange a site assessment and discover your potential savings.
